Chronetic is an open-source time pattern analysis library built to describe time-series data. Written in Java, using Jenetics, an advanced genetic algorithm; Chronetic is able to locate the most prevalent patterns occuring in a given time-series dataset. Patterns are aggregated into a Chronotype and can be translated into a human-readable format with a ChronoDescriptor.
Chronetic begins by extracting temporal facts from the time-series dataset. Using these facts it mutates and breeds combinations in order to find patterns. Accurate patterns reproduce to form more complex patterns with increased accuracy.
Chronetic is fully compatible with ISO calendar systems and most non-ISO calendar systems that define units of years, months and days, etc. Check ChronoUnit for a full list of units comptabile with ChronoPatterns
.
Chronetic fully supports InfluxDB and can be used to analyze pre-existing datasets. For large streaming datasets InfluxDB can also be used as storage, which can be queried quickly, allowing for minimal memory overhead.
Supports parallel execution of evolutionary steps and several parameters to control the population of solutions and offspring as well as fitness & accuracy thresholds, time limits, and more.
The scale, duration, and size of the time-series data makes no difference. Chronetic supports nanosecond to millennia precision or a dataset of two elements to a dataset of two hundred million.
Patterns found in the time-series data can be translated into human-readable text with a ChronoDescriptor
. From simple descriptions to verbose descriptions offering deep insight.
Chronetic
provides solutions using an object called a Chronotype
. A Chronotype
is a genotype characterizing time and can be used to describe a time series dataset. Chronotypes
can be made up of one-to-many Chronosomes
, which represent a particular frequency and/or chronological pattern in a given time series dataset. Chronosomes
under the same Chronotype
cannot share the same time period, represented as a ChronoRange
. Meaing a Chronotype
with multiple Chronosomes
is describing a single time series dataset using multiple distinct frequencies and/or patterns.
For example, suppose a dataset had two distinct events. One happens on Mondays at 10AM and the other happens on Thursdays at 3PM. One Chronosome
would be used to describe the pattern of "Monday at 10AM" and the other would be used to describe "Thursday at 3PM". Since these two Chronosomes
don't share the same time period they can exist under the same Chronotype
to describe multiple patterns occurring in a single time series dataset.
The ChronoPattern
and ChronoFrequency
represents the two ChronoGene
allele types available to a Chronosome
. ChronoPattern
collects chronological patterns and limits the ChronoRange
covered by a Chronosome. The ChronoFrequency
collects the frequency at which the time series data is being collected. The ChronoFrequency
not only serves to provide the frequency of the timeseries dataset but also as a fallback for data which follows no apparent patterns. Those sections of the dataset will be summed up with a single ChronoFrequency
describing the frequency of data collection.
Currently the weakest part of Chronetic. Still working on this. Could use help from anyone that understands multi-objective optimization. The general approach taken is to optimize four objectives. These four objectives being:
Frequency precision describes the precision of a Chronotype
which contains a ChronoFrequency
. Pattern accuracy describes how accurate the Chronotype
's ChronoPattern
sequence is in comparison with the timeseries data by count. Pattern inclusion describes how much of the overall timeseries data is included in the Chronotype
's ChronoPattern
sequence. Finally, temporal inclusion describes the Duration of time a Chronotype
occupies.
The ChronoDescriptor
is used to provide human-readable descriptions of a given Chronotype
. Given that a Chronotype
may have multiple Chronosomes
and those Chronosomes
can have many ChronoPatterns
, the descriptions produced may be verbose on data with no apparent patterns.
The ChronoSeries
represents the time series dataset which Chronetic operates on. It has the ability to be constructed with a collection of events as Instants and Dates as well as with InfluxDB given the database, table, and column names. ChronoSeries
requires at least two timeseries events in order to construct it, but for any insightful descriptions more will be neccessary.
The ChronoRange
represents the period(s) of time in which a given sequence of ChronoPatterns
accounts for. For example, the ChronoPattern
of "every second of November between 2014 to 2017" would create a ChronoRange
in which the range accounted for every second of November 2014 and every second of November 2015, and so on. The ChronoRange
can then be used to query InfluxDB to analyze the timeseries dataset.
ChronoSeries chronoSeries = ChronoSeries.of(
Instant.parse("2011-11-04T08:48:11Z"),
Instant.parse("2012-11-02T09:23:16Z"),
Instant.parse("2013-11-01T09:51:49Z"),
Instant.parse("2014-11-07T08:43:00Z"),
Instant.parse("2015-11-06T08:22:25Z")
);
String description = Chronetic.defaultEngine()
.analyze(chronoSeries).withHourPrecision()
.describe().humanReadable();
//Outputs -> Once a year from 2011 to 2015 on the first Friday of November between 8AM - 10AM
System.out.println(description);
ChronoSeries chronoSeries = ChronoSeries.of(
Instant.parse("2011-11-04T08:48:11Z"),
Instant.parse("2012-11-02T09:23:16Z"),
Instant.parse("2013-11-01T09:51:49Z"),
Instant.parse("2014-11-07T08:43:00Z"),
Instant.parse("2015-11-06T08:22:25Z")
);
Chronetic chronetic = Chronetic.configure()
.populationSize(500)
.survivorsSize(250).offspringSize(250)
.maxGeneration(15).build();
String description = chronetic.analyze(chronoSeries)
.withHourPrecision()
.describe().humanReadable();
//Once a year from 2011 to 2015 on the first Friday of November between 8AM - 10AM
System.out.println(description);
repositories {
jcenter()
maven { url "https://jitpack.io" }
}
dependencies {
compile 'com.github.codebrig:chronetic:v1.0-alpha'
}
<repositories>
<repository>
<id>jitpack.io</id>
<url>https://jitpack.io</url>
</repository>
</repositories>
<dependency>
<groupId>com.github.codebrig</groupId>
<artifactId>chronetic</artifactId>
<version>v1.0-alpha</version>
</dependency>
